SHD SECTOR EXPERTISE

Defence

SHD Composites is actively working on many defence programs with customers around the world

Market Expertise

Advanced composite solutions for the Defence market

Our materials are used for mission-critical applications on next-gen class 1 to 5 UAVs, AAVs and drones including tooling, primary and secondary structures, propellers, heat shields, battery protection, ballistic protection and rocket motors.

SHD’s structural advanced prepreg solutions are also used for naval structures, military vehicles, helmets, body armour, radom's and satellite dishes amongst others, supporting a full range of manufacturing processes and design needs on underwater, surface and airborne defence programs.

We push material performance further with speed and scale, offering:

  • Short 2-3 week lead times and low MOQs

  • Continuous innovation backed by Cambium's AI-driven platform

  • Alternative processing with out of autoclave or rapid cure systems

  • Comprehensive technical data

  • Wide range of reinforcement types for optimal lightweighting and performance

SHD Composites have state-of-the-art production facilities in the US, UK and Europe, offering continuous innovation and local service backed by 2-3 week lead times, low MOQs, and AS9100/EN9100 quality.

We are proudly JOSCAR and Cyber Essentials registered. The Joint Supply Chain Accreditation Register (JOSCAR) serves as the gold standard for supplier compliance within the aerospace, defence and security sectors.

SHD Prepreg composite material

FIND A PREPREG PRODUCT

We offer a wide range of tooling and component prepregs suitable for autoclave, press and oven curing. Using our product selector guide you can browse our products by process, type, resin system and market to find the right product for your needs.

See All Products

Application Areas

01

Propellers

VTC401

DOWNLOAD DATA SHEET
Toughened epoxy system with versatile curing (65°C-120°C) and max Tg dry of 143°C. Excellent for prototyping and series production, with good OOA processing capability.
02

Heat shielding, battery enclosures and nozzles

PS200

DOWNLOAD DATA SHEET
A multi-purpose component PFA prepreg system able to withstand limited time excursions and abuse temperatures up to 1200°C. Formulated and optimised for multiple fire containment applications, PS200 is an industry leading green technology in battery box structures where thermal runaways can occur. PS200 is suitable for use in the most challenging thermal environments and meets aero industry fire protection and insulation standards ISO 2685 and AC 20-135, Revised 1990.

FRVC411

DOWNLOAD DATA SHEET
A versatile fire retardant epoxy component system with a low minimum temperature cure and increased toughness. UL94 V0 certifications on carbon and glass reinforcements.
03

Structures

MTC400

DOWNLOAD DATA SHEET
Curing 135°C to 200°C, a toughened epoxy system with max dry Tg of 225°C and wet Tg > 160°C. Excellent property retention temperature up to 180°C, with good chemical resistance and typically used for components around the engine and pressure pipes.

MTC400-1

DOWNLOAD DATA SHEET
Toughened epoxy system curing 135°C-180°C and providing dry Tgs of 145°C and 205°C respectively. Typically used on monocoque and elevated temperature structures has excellent retention of properties up to 150°C. Supported by extensive database.

VTC401

DOWNLOAD DATA SHEET
Toughened epoxy system with versatile curing (65°C-120°C) and max Tg dry of 143°C. Excellent for prototyping and series production, with good OOA processing capability.
04

Radomes

CEM100

DOWNLOAD DATA SHEET
Cyanate ester system with a maximum (limited) service temperature of 350°C from 250°C initial cure. Short exposures to 400°C possible.

CEM160

DOWNLOAD DATA SHEET
120-135°C initial cure, modified, cyanate ester system with a max dry Tg capability of 275°C, after post-cure. Meets low-outgassing requirements.
See Tooling
